l The TS JC1 automatic PCB testing machine is composed of automatic PCB feeding device,movable table, testing device, control system and a tester.

l It can test the PCB power consumption, overcharge protection,over-charged recovery voltage, over-discharge protection, over-discharge recovery voltage, over-current protection functions of a single lithium battery.

l Automatic entry and exit, high test speed,high accuracy,easy to operate,does not need the guarding of a special person.

l The automatic PCB feeder sends out a stack of PCB one by one, which can fill thousands of PCB one time.

l The moving workstation catches the PCB provided by the automatic feeding plate device and automatically moves it to the test position according to the set data for testing.

l The tested PCB will be automatically sent from the moving station and dropped into the receiving box.

l The defective products are automatically re-tested. After the re-tested, the defective products are automatically identified. The number of defective PCB is also recorded by the system.

l The position of the detection needle can be adjusted at will to meet the test of different types of PCB.

l The marker adopts large oil pen, durable and easy to replace.

l Using touch screen to set parameters. Simple and clear.

l Up to 100 groups of PCB parameters can be stored in the system for easy invocation.
